USD 4.965
Tensión de entrada: AC152-456;
Frecuencia de entrada: 50Hz
Factor de potencia: ≥ 0.99
Eficiencia: ≥ 93.0%
Aislación: IP67
Temperatura de trabajo: – 40 ℃ ~ +75 ℃
Temperatura de almacenaje:- 40 ℃ ~ + 95 ℃
Can:2.0
Auxiliares: Salida 12V 5 A
Indicador de estado de carga
Ruido: ≤45 db
Dimensión: 294 ×210× 111 (mm)
Peso Neto: 5.9kg
Input Characteristic:
Rated Input Voltage
380VAC (3 phase with neutral line)
Output power reduced to 6.6kw @ 220V single phase input
Input Voltage Range 152～456VAC
Rated AC frequency 50Hz
Input frequency range 45～65Hz
Starting Impulse Current ≤32A
Input power factor ≥0.99（@380Vin,Pomax）
Output Characteristic:
Rated Output Power 19.8KW
Output Voltage Range(V) 0-180
Output Current Range(A) 0-132
Voltage regulation accuracy: ±1%
Current regulation accuracy: ±0.5A（Io≤10A）&≤±5%（Io>10A）
Ripple coefficient of voltage: ≤1%
Output Response Time ≤200mS
Typical Efficiency ≥≥92%
Protective Characteristic
Over and Under Voltage Protection
Input over and under voltage shutdown can be self-recovery, output over and under voltage shutdown can be self-recovery.
Output Reverse
Connection and Short Circuit Protection
Output short circuit and reverse connection shutdown can be self-recovery
Over Temperature Protection
When the heat sink temperature is higher than 75 ° C, it will reduce
the output power. And it will disconnect the circuit when the
temperature is higher than 95 ° C. It will restore the output when the
charging temperature is lower than 85 ° C.
